Description
The BUZZYBEE 4 is a very simple designed; simple, strong, secure and the best value for your money.
Basic ergonomics
The BUZZYBEE 4 is very compact and light for a 4 bike carrier with a weight of 15.5kg!
Very compact geometry but fits most bike sizes!
Key features of the BUZZYBEE 4
Assembly: Even though it is not assembled, BUZZYBEE 4 is very easy to put together: assemble the wheel support frame to the base using 8 screws, assemble the light support with 2 more screws, install the license plate, slide in the plastic wheel supports, fit the rack to the tow ball with no tools needed and you are ready to go!
Fitting to the car: When you first place the BUZZYBEE 4 on the tow ball it supports itself – you can let go of it and it won't fall to the ground. You'll then take the weight again, spin the tightening knob until it's tight, and lock it. BUZZRACK's carriers comply with the very exacting standard XPR-18-904-4 and therefore include an anti-sway tensioner; this has an integrated handle and 2 or 3 turns are usually sufficient.
Lighting system: The BUZZYBEE 4 comes with a 3 function 7 pin flat plug for AUS/NZ.
Carrying bikes
- The wheel holders will accommodate most wheelbases, even small children's bikes. You can reverse the wheel supports for the really small bikes.
- The long wheel rubber-padded wheel straps hold tyres up to 3.25" wide; pull on them to tighten, and use the quick release to loosen
- The BUZZYBEE 4 is entirely suitable for carbon frame bikes; the rubber bike frame pads and high resistance straps hold any type of tube firmly but gently.
- The maximum permitted load is 60kg, with no bike weighing more than 20kg
- The down tube size is limited to 75mm diameter (3"); whatever bikes you have, always load the heaviest bikes nearest to the car
Other features and basic specifications
- The patented conical fitting fits to all tow balls, even to the bolt-on tow balls we see occasionally that do not meet standards for neck length or ball diameter.
- A reminder that it locks to the tow ball.
- The BUZZYBEE 4 sits high on the tow ball, well clear of speed bumps and other hazards such as steep ferry ramps.
- The build quality – tube bending, welding, rust proofing, painting, component quality, is exemplary. The whole carrier looks and feels like the class act it is. All tools you might need are provided.
The maximum permitted load you can carry is also determined by the tow bar nose weight; you will need to check you don't exceed this before using any tow ball mounted bike carrier. Requires 65mm clearance from center of tow ball to rear of vehicle. Visit buzzrack.com for detailed safety and fitting instructions.
NOT TO BE USED ON MOTORHOMES, CARAVANS, OR TRAILERS
Specifications
| Bike ebike suitable: | Yes suitable for eBikes as long as bike is within carriers max bike weight. |
| Bike Rack Bike Attachment: | Frame Hold |
| Bike Rack Bike Wheel Base: | Adjustable wheel holders. MIN: 61 cm / MAX: 119 cm |
| Bike Rack Carbon frame compatible: | YES |
| Bike Rack dimensions: | 878 x 960 x 740 |
| Bike Rack distance between Bikes: | 200 / 180 / 200mm |
| Bike Rack Fits Vehicles with Exterior Tyre: | Refer to rack diagram and measure based on your vehicle |
| Bike Rack Folded dimensions: | 878 x 960 x 280 |
| Bike Rack Lights & Number Plate holder: | YES |
| Bike Rack Lockable: | YES Rack locks to tow ball. Cable lock for bikes sold separately |
| Bike Rack Maximum Total weight: | 60 kg |
| Bike Rack Maximum Tyre Width: | 3.25" |
| Bike Rack Maximum Weight per bike: | 15 kg |
| Bike Rack Number of Bikes: | 4 Bikes |
| Bike Rack Off-road Load limit: | No |
| Bike Rack Vehicle Attachment: | TOWBALL (50mm) |
| Bike Rack Vehicle Rear Access: | Non-tilting |
| Bike Rack Weight: | 15.5 kg |
| Colour: | Black |
| Manufacturer SKU: | BR-4-BUZZYBEE |
| Product Type: | BIKE RACK - TOWBALL PLATFORM |
| Sport / Activity: | Biking |
| Suitable for use on Trailers or Caravans: | No |
| Weight: | 18.000000 |
| Summary: | The BUZZYBEE 4 is a very simple designed; simple, strong, secure and the best value for your money. |
